Description
| ECO-RAY01 | |
| SPECIFICATION | |
| Tube Voltage | 60kV |
| Tube Current | 2mA |
| Maximum Time | 2s |
| Nominal Electric Power | 0.12kW |
| Maximum Inverter Frequency | 100kHz |
| Time Adjustment Range | 0.01～2s |
| Battery | DC 24.0V, 950mAh,  ±10% |
| Charger Input | AC 100～240V, 1.3A, ±10% |
| Charger Output | DC 25.2V, 1.0A |
| Frequency | 50/60Hz, ±1Hz |
| Internal Resistance Of Power Supply | ＜2Ω |
| Distance From Focus To Skin | 20.5cm±0.5cm |
| X-Ray Field | Round, Φ 5.7cm±0.3cm |
| Total Filtration | 1.75mm Al |
| Additional Filtration | 1.0mm Al |
| Surface Leakage Radiation | ＜0.25mGy/h |
